Designed for industrial-scale efficiency and consistent molding quality, the 8-Station Rubber Mould Making Machine delivers exceptional performance in producing rubber parts such as shoe soles, gaskets, seals, and more. With an hourly output of 80–200 pairs, this machine is ideal for manufacturers seeking high productivity and precision in every cycle.
Equipped with a dual-screw system (∮65/∮75 mm) and a maximum injection volume of 1080 to 1400 cm³, it supports the injection of large and complex rubber components. The maximum injection pressure of 2200/1690 Kgf/cm² ensures excellent material flow and mold filling, while the 180-ton clamping force guarantees tight sealing for accurate part formation.
Key Specifications:
| MODELO | UNIDAD | parámetros |
| Número de puestos de trabajo | Estaciones | 8 |
| Productividad por hora | Pares | 80-200（模/小时） |
| Diámetro del tornillo | mm | ∮65/∮75 |
| Volumen máximo de inyección | cm³ | 1080/1400 |
| Presión máxima de inyección | Kgf/c㎡ | 2200/1690 |
| Fuerza de sujeción del molde | Toneladas | 180 |
| Espacio del molde (L×A×H) | mm | 450*380*220/260 |
| Motor | Kw | 18.5+15*2 |
| Potencia de las bandas de prueba | Kw | 48KW+9KW（mold temperature controller） |
| Peso (aproximado) | toneladas | 16.8T |
Características:
-
Multi-station design for continuous operation and faster cycle times
-
Dual-screw system for flexible injection control and material adaptability
-
High-pressure molding for fine detail and dimensional accuracy
-
Advanced heating system with independent mold temperature control
-
Durable structure ideal for long-term industrial operation
Aplicaciones:
Widely used in the production of rubber shoe soles, automotive rubber parts, medical-grade components, and custom industrial rubber products.
Boost your manufacturing efficiency with this high-output Rubber Mould Making Machine—engineered for reliability, speed, and superior mold precision.
